StreptaClick® HRP
Price range: 400 € through 4730 €
StreptaClick® HRP Multiplex IHC Kit is an accelerated heat-treatment-free multiplex Tyramide Signal Amplification (TSA) staining solution for up to nine markers (8 antibodies + DAPI) for fixed cells, FFPE samples and frozen tissues. This comprehensive kit is designed for researchers who demand ease of use and flexibility in multiplex immunohistochemistry (IHC).
The kit includes everything needed to label biotinylated primary antibodies with horseradish peroxidase (HRP) enzyme in solution utilizing our modified streptavidin StreptaClick®. As StreptaClick® removes the issue of antibody aggregation through monovalent biotin binding it is particularly suited for labeling primary biotinylated antibodies. The kit also features a novel HRP Quench Buffer that eliminates the need for antibody-stripping by heat-treatment such as boiling between cycles. This feature maintains tissue morphology over multiple staining cycles making it ideal for both frozen and FFPE tissue sections, and higher degrees of multiplexing than comparable solutions.
In combination, these features makes the protocol highly automation-friendly, while results for manual staining of six markers + DAPI are achievable in one day.
Order or request further information
Request a quote or order
Request a quote or order with payment by invoice by sending us an email via the button above. When ordering, please include information on the products you wish to order, organization, VAT number (only EU countries), delivery address, and invoice address. Please also state contact person and phone number for delivery by courier.
We ship globally – a shipping cost of €50 is added to countries within the EU and €80 to all other countries. Upon request we can also charge in $USD for payments by invoice.
Webshop
Orders can also be placed through our webshop via the form below. Once a product has been added a popup will appear with the choice of proceeding to checkout or adding additional products. The shopping cart icon at the top right corner also takes you to checkout.
At checkout you will have the choice of secure payment by credit card via Stripe, Apple Pay, Google Pay or invoice. Shipping charges are added automatically.
NB: VAT is not added to the final cost under Article 138 VAT directive (other EU countries) and 146 VAT directive (export to non-EU countries).
Select your StreptaClick® HRP Kit:
StreptaClick® HRP Workflow
How it works
Biotinylated antibodies pre-mixed with StreptaClick® operate similarly to directly conjugated antibodies, thereby eliminating the need for secondary antibodies. The StreptaClick® labeling reaction is extremely efficient, permitting the labeling of any antibody volume, even down to microliters. This is particularly beneficial when setting up new experiments.
Quick Results, Less Hands On Time
With StreptaClick® HRP you can complete a 7-color Tyramide Signal Amplification (TSA) multiplex IHC within a single day (DAPI + 6 biotinylated antibodies). Each biotinylated antibody is labeled with HRP by the fast StreptaClick® reaction, and the kit includes an HRP Quench Buffer buffer that efficiently quenches HRP activity between staining cycles.
Quench HRP activity avoids the slow, inconvenient and harsh boiling step to strip off antibodies required by other solutions between staining cycles. Added benefits of the HRP Quench Buffer include preserved tissue morphology, higher attainable protein biomarker multiplexing levels and a protocol that is automation-friendly. This also results in that optimization of the order in which antibodies are added to the tissue is virtually eliminated.
Nine-Color TSA method for frozen sections and FFPE from mice, humans, rats, and other species
The StreptaClick® HRP solution is a must for any manual or automated TSA staining. The kit comes with a HRP quenching buffer that eliminates the need for boiling, which not only accelerates each color cycle but also makes the kit highly beneficial for frozen tissue sections. The quenching buffer effectively silences the HRP signal from the previous round while preserving the morphology of the frozen tissue. Hence, the StreptaClick® HRP kit provides a rapid method for multiplex TSA IHC on both FFPE and frozen sections, with antibodies from any host, and on tissues from mice, humans, rats, and other species. Currently we have optimized protocols for up to nine-color staining (8 tyramides + DAPI), but the upper limit is likely higher given suitable dyes and imaging systems.
Rapid manual or automated protocol
Automation is also facilitated by the rapid protocol and unique features. The use of primary antibodies and our HRP quenching buffer makes it especially amenable for automated staining. External partners have developed a protocol on the Leica Biosystems BOND RX IHC staining system, and protocols for other systems are in development.
Imaging
Fluorochrome specifications
| Name | Absorption max | Emission max |
| Tyramide CF®405S | ||
| Tyramide CF®430 | 426 nm | 498 nm |
| Tyramide 488 | 494 nm | 517 nm |
| Tyramide 555 | 555 nm | 572 nm |
| Tyramide 594 | 590 nm | 617 nm |
| Tyramide 647 | 648 nm | 671 nm |
| Styramide iFluor 700 | ||
| Styramide iFluor 750 | 757 nm | 779 nm |
The fluorochromes we provide are carefully chosen to align with most common filter sets.
However, the inclusion of more fluorochromes in your immunostainings adds complexity. For reliable imaging of tissues stained with up to seven colors (7-plex IHC) without requiring spectral unmixing, we offer a patented combination of filter sets- SpectraSplit® 7. SpectraSplit® 7 accommodates all the channels in the chart and performs excellently with AZDyes and a variety of commercial dyes, such as AlexaFluor® dyes, FITC, TRITC, Cy3, Cy5, Cy7 dyes, and many of the OpalTM dyes. Learn more
Pushing the boundaries further we have recently launched the SpectraSplit® 10 filter set, enabling imaging of up to ten colors without spectral unmixing. Again our design principle has been to make it an open solution, aligning the channels with most commonly used dyes from a variety of manufacturers.
SpectraSplit® 7
| Channel | Traditional dyes | StreptaClick® dyes |
| S-Split Blue (375) | DAPI/Hoecht | DAPI |
| S-Split Cyan (435) | CFP | Tyramide CF®430 |
| S-Split Green (490) | FITC | Tyramide 488 |
| S-Split Orange (545) | Cy3/TRITC | Tyramide 555 |
| S-Split Red (590) | Texas Red | Tyramide 594 |
| S-Split Far-red (650) | Cy5/Cy5.5 | Tyramide 647 |
| S-Split Infra-red (740) | Cy7 | Styramide iFluor® 750 |
SpectraSplit® 10
| Channel | Traditional dyes | StreptaClick® dyes |
| S-Split DAPI(365) | DAPI/Hoecht | DAPI |
| S-Split Blue (410) | Tyramide CF®405S | |
| S-Split Cyan (435) | CFP | Tyramide CF®430 |
| S-Split Green (495) | FITC | Tyramide 488 |
| S-Split Orange (545) | Cy3/TRITC | Tyramide 555 |
| S-Split Red (590) | Texas Red | Tyramide 594 |
| S-Split Far-red (650) | Cy5/Cy5.5 | Tyramide 647 |
| S-Split Far-red (695) | Styramide iFluor® 700 | |
| S-Split Infra-red (740) | Cy7 | Styramide iFluor® 750 |
Contact us to learn more or order.
Frequently Asked Questions
Yes, StreptaClick® HRP heat-free TSA is easy to use and well-suited for those new to the field. The heat-free protocol considerably reduces the optimization time required to build a multiplex antibody panel.
Through its TSA and HRP block system, the need for secondary antibodies is eliminated. This improves reproducibility and streamlines the workflow compared to indirect immunofluorescence (IF), while preserving target epitopes and tissue morphology.
Up to 5-7 antibodies can be applied within a single day depending on the required incubation time of each antibody, significantly reducing the total experiment time. On average one staining cycle takes 1.5 hours.
250 reactions is the number reactions in singleplex that the kit is sufficient for. If all reactions were to be used for 5-plex experiments, the kit is sufficient for 250/5, or 50 five-plex reactions.
250 reactions is the number of reactions in singleplex that the kit is sufficient for. If all reactions were to be used for 5-plex experiments, the kit is sufficient for 250/5, or 50 five-plex reactions.
The reason more tyramide dyes are included in the 3 and 5 color kits is that some optimization may be required for the tyramide concentration; ex. some users prefer 1/50 dilutions, and sometimes 1/200 is sufficient.
Yes, StreptaClick® HRP heat-free TSA has been developed and validated for use with biotinylated primary antibodies. Biotinylated primary antibodies can be purchased from a number of vendors including our listed partners, either off the shelf or as custom orders. Alternatively, carrier free antibodies (ie no carrier protein such as BSA, and ideally free from sodium azide) can easily be biotinylated with our BiotinPure™ Antibody Biotinylation Kit. BiotinPure™ is an easy and complete solution only requiring a benchtop centrifuge.
| StreptaClick HRP | BiotinPure™ Antibody Biotinylation Kit (5 reactions), HRP Quench Buffer kit (250 reactions), StreptaClick® HRP Complete 4-color TSA IHC kit (250 reactions), StreptaClick® HRP Complete 6-color TSA IHC kit (500 reactions), StreptaClick® HRP Complete 7-color TSA IHC kit (500 reactions), StreptaClick® HRP Complete 8-color TSA IHC kit (750 reactions), StreptaClick® HRP Complete 9-color TSA IHC kit (750 reactions), StreptaClick® HRP Multiplex IHC kit (250 reactions), StreptaClick® HRP Multiplex IHC kit (90 reactions), Tyramide 3-Dye kit (300 reactions), Tyramide 5-Dye kit (500 reactions), Tyramide 6-Dye kit (600 reactions), Tyramide 7-Dye kit (700 reactions), Tyramide 8-Dye kit (800 reactions) |
|---|
Ordering information
| Cat no. | Product |
| 69B8181-1 | StreptaClick® HRP Complete 9-color TSA IHC Kit (750 reactions) |
| 68B8181-1 | StreptaClick® HRP Complete 8-color TSA IHC Kit (750 reactions) |
| 67B8181-1 | StreptaClick® HRP Complete 7-color TSA IHC Kit (500 reactions) |
| 66B8181-1 | StreptaClick® HRP Complete 6-color TSA IHC Kit (500 reactions) |
| 65B8181-1 | StreptaClick® HRP Complete 5-color TSA IHC kit (500 reactions) |
| 64B8181-1 | StreptaClick® HRP Complete 4-color TSA IHC kit (250 reactions) |
| 6008182-1 | StreptaClick® HRP Multiplex IHC kit (90 reactions) |
| 6008181-1 | StreptaClick® HRP Multiplex IHC kit (250 reactions) |
| 6008180-1 | HRP Quench Buffer kit (250 reactions) |
| 60081-1 | Tyramide 8-Dye kit (800 reactions) |
| 60071-1 | Tyramide 7-Dye kit (700 reactions) |
| 60061-1 | Tyramide 6-Dye kit (600 reactions) |
| 60051-1 | Tyramide 5-Dye kit (500 reactions) |
| 60031-1 | Tyramide 3-Dye kit (300 reactions) |
| 600DAP1-1 | DAPI (1000 reactions) |
| 9000051-1 | BiotinPure™ Antibody Biotinylation Kit (5 reactions) |
Please contact us to inquire about larger pack sizes and custom kit configurations.
StreptaClick® HRP Multiplex IHC kits
The kits contain StreptaClick® HRP antibody labeling reagent for labeling of biotinylated antibodies, a novel horseradish peroxidase (HRP) Quench Buffer (now also available as a standalone product), and Tyramide Amplification Buffer Plus (compatible with all common tyramide dyes from various vendors).
The staining protocol does not require heat treatment such as boiling between cycles, and is ideal for direct labeling of primary antibodies for higher degrees of multiplexing compared to working with secondary antibodies. Compatible with FFPE and frozen tissue sections, and fixed cells.
The number of reactions equals the number of possible singleplex TSA staining reactions when using the standard dilutions of the protocol. Divide by the number of markers in multiplex for the number of possible slides, ex 250/5 = 50 five-plex slides.
Tyramide Dye kits
All tyramide dye kits include PBS buffer and anhydrous DMSO to prepare tyramide stock solutions.
- Tyramide 8-Dye kit (800 reactions): includes 100 reactions each of Tyramide CF405S, Tyramide CF®430, Tyramide 488, Tyramide 555, Tyramide 594, Tyramide 647, Styramide iFluor 700 and Styramide iFluor 750 when used at the recommended 1/50 working dilution (subject to user optimization) for a total of 800 singleplex reactions.
- Tyramide 7-Dye kit (700 reactions): includes 100 reactions each of Tyramide CF®430, Tyramide 488, Tyramide 555, Tyramide 594, Tyramide 647, Styramide iFluor 700 and Styramide iFluor 750 when used at the recommended 1/50 dilution (subject to user optimization) for a total of 700 singleplex reactions.
- Tyramide 6-Dye kit (600 reactions): includes 100 reactions each of Tyramide CF®430, Tyramide 488, Tyramide 555, Tyramide 594, Tyramide 647, and Styramide iFluor 750 when used at the recommended 1/50 working dilution (subject to user optimization) for a total of 600 singleplex reactions.
- Tyramide 5-Dye kit (500 reactions): includes 100 reactions each of Tyramide CF®430, Tyramide 488, Tyramide 555, Tyramide 594, Tyramide 647 when used at the recommended 1/50 working dilution (subject to user optimization) for a total of 500 singleplex reactions.
- Tyramide 3-Dye kit (300 reactions): includes 100 reactions each of Tyramide 488, Tyramide 555 and Tyramide 647 when used at the recommended 1/50 working dilution (subject to user optimization) for a total of 300 singleplex reactions.
DAPI (1000 reactions)
Product includes DAPI for 1000 reactions. Dilute in H2O.
StreptaClick® HRP Complete TSA IHC kits
The complete kits contain all components necessary for 4, 6, 7, 8 dye Tyramide Signal Amplification (TSA) + DAPI multiplex staining. Just add biotinylated primary antibodies.
- StreptaClick® HRP Complete 9-color TSA IHC Kit (750 reactions) includes: StreptaClick® HRP Multiplex IHC kit (750 reactions) + Tyramide 8-Dye kit (800 reactions) + DAPI (1000 reactions).
- StreptaClick® HRP Complete 8-color TSA IHC Kit (750 reactions) includes: StreptaClick® HRP Multiplex IHC kit (750 reactions) + Tyramide 7-Dye kit (700 reactions) + DAPI (1000 reactions).
- StreptaClick® HRP Complete 7-color TSA IHC Kit (500 reactions) includes: StreptaClick® HRP Multiplex IHC kit (500 reactions) + Tyramide 6-Dye 6 kit (600 reactions) + DAPI (1000 reactions).
- StreptaClick® HRP Complete 6-color TSA IHC Kit (500 reactions) includes: StreptaClick® HRP Multiplex IHC kit (500 reactions) + Tyramide 5-Dye kit (500 reactions) + DAPI (1000 reactions).
- StreptaClick® HRP Complete 4-color TSA IHC Kit (500 reactions) includes: StreptaClick® HRP Multiplex IHC kit (250 reactions) + Tyramide 3-Dye kit (300 reactions) + DAPI (1000 reactions).
BiotinPure™ Antibody Biotinylation Kite TSA IHC kit
Separate kit for biotinylation of 5 carrier-free antibodies. See BiotinPure™ Antibody Biotinylation Kit for more information.
RESOURCES
FLYER
StreptaClick® HRP flyer
USER MANUAL
User Manual StreptaClick® HRP
USER MANUAL (Tyramide Dyes)
User Manual Tyramide Dyes
SDS
SDS EN SCHRP KIT - Antibody labeling reagent (StreptaClick HRP)_2.1_60810
SDS EN SCHRP KIT - 3% H2O2_2.1_60806
SDS EN SCHRP KIT - Biotin block buffer_2.1_60804
SDS EN SCHRP KIT - Block activator_v2
SDS EN SCHRP KIT - HRP block buffer_2.1_60805
SDS EN Tyramide dyes_1.0_76444
SDS Biotium Tyramide Amplification Buffer PLUS
